4.4. Client Side Map Descriptors
4.4.1. FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name
Name of this Map
Descriptor Up to 32 alphanumeric
characters
Data_Array_Name
Name of Data Array where
data is to be stored in the
FieldServer One of the Data Array
names from “Data Array”
section above
Data_Array_Location
Starting location in Data
Array 0 to maximum specified in
“Data Array” section above
Function
Function of Client Map
Descriptor
RDBC
WRBX ( Only for use to
execute remote control
commands. See Map
Descriptor examples. )
Length
The length of the Map
Descriptor
1
4.4.2. Driver Specific Map Descriptor Parameters
Column Title Function Legal Values
Node_Name
Name of Node to fetch data
from
One of the node names
specified in “Client Node
Descriptor” above
Parms_DA
Specifies the name of the
Data Array that will hold
remote control command
parameters
0 to 20 alphanumeric
characters
Parms_DA_Offset
Specifies the offset into the
parameters Data Array
where the remote control
parameters start
0 to maximum offset for
length of the parameter
Data Array
4.4.3. Timing Parameters
Column Title Function Legal Values
Scan_Interval Rate at which data is polled >0.1s
