16
MB15C02
■
TYPICAL CHARACTERISTICS
1. fin Input Sensitivity
2. OSC
IN
Input Sensitivity
Input sensitivity (dBm)
20.0
10.0
0.0
− 10.0
− 20.0
− 30.0
− 40.0
− 50.0
− 60.0
0 100 200 300 400 500 600 700 800 900 1000
fin input frequency vs. Input sensitivity
fin input frequency (MHz)
Ta = +25 ° C
V
DD
= 1.0 V
V
DD
= 1.2 V
V DD = 1.3 V
V DD = 1.5 V
Input sensitivity (dBm)
20.0
10.0
0.0
− 10.0
− 20.0
− 30.0
− 40.0
− 50.0
− 60.0
0 50 100 150 200 250 300 350 400 450 500
OSC IN input frequency vs. Input sensitivity
OSC
IN
input frequency (MHz)
Ta = +25 ° C
V DD = 1.0 V
V DD = 1.2 V
V
DD
= 1.3 V
V
DD
= 1.5 V
