FS-8700-36 Weigh-Tronix Driver Manual
FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042
Visit our website: www.fieldserver.com E-mail: [email protected]
Page 5
2.1.2.3 Client Side Map Descriptors
Section Title
Map_Descriptors
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric
characters
Data_Array_Name Name of Data Array where
data is to be stored in the
FieldServer One of the Data Array names
from “Data Array” section above
Data_Array_Offset Starting location in Data Array 0 to maximum specified in “Data
Array” section above
Function Function of Client Map
Descriptor RDBC, WRBC, WRBX
Node_Name Name of Node to fetch data
from One of the node names
specified in “Client Node
Descriptor” above
Address Starting address of read block 0
Length Length of data array 3
Data_Array_Low_Scal
e* Scaling zero in Data Array -32767 to 32767, default 0
Data_Array_High_Scal
e* Scaling max in Data Array -32767 to 32767, default 100
Node_Low_Scale* Scaling zero in Connected
Node -32767 to 32767, default 0
Node_High_Scale* Scaling max in Connected
Node -32767 to 32767, default 100
Example
// Client Side Map Descriptors
Map_Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Location, Function, Node_Name, Address, Length
wtio_MAP, DA_AI, 0, RDBC, Scale1, 0, 3,
