FS-8700-36 Weigh-Tronix Driver Manual
FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042
Visit our website: www.fieldserver.com E-mail: [email protected]
Page 3
G {gross} lb \r\n
T {tare} lb \r\n\
N {net} lb \r\n
Select Print Format = 1
Select Port = 1
f. Close editor
g. Save configuration
h. Download Com 1 or Com 2
Wait for double beep
Wait for single beep
i. Exit WI-130 config
j. Attach Model FieldServer FieldServer per dwg etc.
2.1.2 Configuration File Structure
Note that * indicates an optional parameter, with the bold legal value being the default.
2.1.2.1 Data Arrays
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Provide name for Data Array Up to 15 alphanumeric
characters
Data_Format Provides data format INT16, INT32, BIT, FLOAT
Data_Array_Length Number of Data Objects 1-10,000
Example
// Data Arrays
Data_Arrays
Data_Array_Name,
Data_Format, Data_Array_Length
DA_AI, Float, 100
