Finishes up the job neatly:
GXE deburring machine
An ideal addition to the GRIT GX program: The deburring machine
GXE completes the final task. It is highly effective for deburring
pipes, profiles and flat materials. The broad spectrum of GRIT
deburring brushes solves nearly all deburring jobs.
 For deburring pipes and profiles
 Connection for extraction option available
 Employable as polishing machine when
using the appropriate polishing wheels
 High operational reliability due to
integrated safety switch with motor
protection
 Broad range of wire brushes available
(see accessories)
Power 2.2 kW (3.0 HP)
Voltage US 220 / 440 V (3~)
Amps US 10 or 5
Voltage CAN 575 V (3~)
Amps CAN 3.8
Speed 1,800 rpm
Tool dimension max. Ш 10" Ч 2 ⅜"
Connecting cable 6.6 ft
Weight 71 lbs
Part number 7 901 05
Included in delivery: Motor protection switch, under voltage
release. *Brush not included in delivery. Stand is an optional
accessory
GXE
Technical data
