P S - P R O H T - P O W E R CO N D I T I O N E R / S E Q U E N C E R
Current rating:
20 Amps (2400 Watts at 120 VAC)
Input Voltage:
85 to 264 VAC without damage
Mains Wiring analyzer: Detects one normal mode and five fault modes
Delay Intervals:
Total elapsed ON or OFF delay time adjustable
from 1-60 seconds, with a single trimpot:
ON sequence:
Delay 1 outlets go on immediately with switch.
Delays between outlets 1 and 2, and 2 and 3,
adjustable from 1-30 seconds each
OFF sequence:
Delay 3 outlets go off immediately with switch.
Delays between outlets 3 and 2, and 2 and 1,
same as ON delays
Remote Switch:
Screw terminals, 2 for switch, 2 additional for
optional LED (22 ga. minimum)
Spike Protection Modes: Line to neutral
Clamping Voltage, all modes:
180V peak
Response time:
1 nanosecond
Maximum surge current:
11,000 amps (8 x 20mS pulse)
Maximum spike energy: 550 joules total
Noise attenuation:
Differential mode: greater than 60 dB; 1 to 200
MHz
Dimensions:
1.75” H x 19” W x 10” D.
Weight:
6 lbs (2.7 kg).
Construction:
Steel chassis, zinc chromate plating; .125”
brushed and black anodized aluminum front panel;
glass epoxy printed circuit boards.
Power Consumption:
11 watts
Safety Agency Approvals:
UL, C-UL.
PS-PRO HT SPECIFICATIONS
