TYPE: PR 372
PART NUMBER: 22-8503 (120V)
22-8533 (240V) Aust
22-8543 (230V) UK
22-8563 (230V) Eur
22-8573 (100V)
POWER REQUIREMENTS: 100V AC, 50/60 Hz 450W
120V AC, 60 Hz, 450W
230V AC, 50 Hz, 450W
240V AC, 50 Hz, 450W
POWER AMPLIFIER SECTION
POWER OUTPUT: 80W R.M.S. per channel, (160W R.M.S. Total)
into 8
Ω
@ <0.18% T.H.D., both channels driven
SENSITIVITY : 0.965V (both channels)
PREAMP SECTION
INPUT IMPEDANCE: 18.2k
Ω
(line) 1.82k
Ω
(mic)
SENSITIVITY FOR
FULL POWER :
2.1 V (line) 210 mV (mic) Nominal Controls
23 mV (line) 2.3 mV (mic) Maximum Controls
TONE CONTROLS: Treble: +/-15 dB @ 15 kHz
Mid: +/-15 dB @ 750 Hz
Bass: +/-15 dB @ 30 Hz
SPEAKER COMPLEMENT: One Fender Special Design 12” Speaker (P/N 047539)
One Fender Special Design 10” Speaker (P/N 053614)
Single Piezo Horn (P/N 049260)
DIMENSIONS: Height: 33 in 83.8 cm
Width: 19.5 in 49.5 cm
Depth: 13.5 in 34.3 cm
WEIGHT: 82 lbs 37.3 kg
Fender ® , SFX ® , Tone-Master ® and Princeton ® Chorus are
registered trademarks of the Fender Musical Instruments
Corporation.
The SFX Effect, patent pending, is manufactured under license
from Aspen Pittman and Drew Daniels of SFX Technology.
Product specifications are subject to change without notice.
A PRODUCT OF:
FENDER MUSICAL INSTRUMENTS CORPORATION
CORONA, CA 91720 USA
SFX KEYBOARD 200 SPECIFICATIONS
