7
If the SFX Keyboard 200 is set up but
does not function, check the
following items:
• Is the power cord properly plugged into an
electrical outlet?
• Is there power at the outlet?
• Are the control knobs turned above 1?
• Is the volume control on the instrument turned up?
• Are the control knobs on your external
equipment turned above 1?
• Is the power cord on your external equipment
properly plugged into an electrical outlet?
• Is the microphone turned on?
• Are any cords cut, frayed or damaged?
• Are the DSP control knobs turned above 1?
• Is the instrument / microphone properly plugged
into the amplifier?
(Eliminate any effects pedals and try using another cord.)
If after checking all of the above your amplifier is still
not performing correctly, consult your nearest
authorized Fender Service Center.
Your SFX Keyboard 200 is covered in
a tough, soil resistant synthetic
indoor/outdoor carpet for long life and
lasting good looks. To clean the
carpeted cabinet, use a brush and
vacuum to wipe away any smudges
or dirt. For stubborn stains, a sponge
with a light soapy solution may be used. Avoid
spilling liquids on the input panel, grille and speakers.
REMEMBER TO UNPLUG THE POWER CORD
BEFORE CLEANING AND WAIT UNTIL THE UNIT
IS COMPLETELY DRY BEFORE PLUGGING IT IN.
The SFX Keyboard 200 has a variety of
connectors on its input / output panels.
Below is a chart listing the various types
and their pin outs.
TROUBLESHOOTING
COVERING CARE
CONNECTIONS
Jack Style Connection Pin Out
SUB
LINE
OUT
1/4"
TRS
LINE
INPUTS
1/4"
TRS Tip = POS
Ring = NEG
Sleeve = GND
INSERTS
1/4"
TRS
Balanced
Input
LINE
OUTPUTS
1/4"
TRS Balanced
Output
MIC
INPUT
Balanced
Input
XLR
Female
Pin 1 = GND
Pin 2 = POS
Pin 3 = NEG
Tip = Send
Ring = Return
Sleeve = GND Input /
Output
Tip = POS
Ring = NEG
Sleeve = GND
Balanced
Output
Tip = POS
Ring = NEG
Sleeve = GND
