3 3
Assembled Parts Assembled Parts
2 Front Bushings 2 Cap Nut Covers
4 Wheel Covers
Steering Wheel
Key
Cup Holder
4 Roof Posts
Roof
Rear Axle
2 Axle Mounts
2 Front Axles
4 Hubcaps 4 Wheels
Frame
Retainer Sounds and Lights Box
2 Rear Bushings
ALL SHOWN ACTUAL SIZE
Note: Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten the screws.
For your convenience, we’ve included extra cap nuts!
.354” Cap Nuts – 5
#8 x 3 /
4
” Screw – 11
3 /
16 16
” Washer – 4
#6 x 1 /
2
” Screw – 3
Note: Label sheet not shown.
