Power Controls
To operate the router:
1. Set the motor speed by turning the variable speed
control knob to the desired speed according to the router
speed settings table on page 13.
2. Start the router by pulling up on the power switch.
3. If desired, lock the power switch in the on position by
holding in the trigger lock button, and then release the
power switch.
4. To release the trigger lock, pull up then release the
power switch.
The OF 1400 EQ router has a removable power cord for
added convenience. To install the power cord:
1. Insert the cord into the receptacle on the router's handle
with the keyway lined up with the key.
2. Twist the locking knob in the direction shown.
3. Reverse the procedure to remove the cord.
Technical Specifications
Power Consumption 1400 Watts (12 amps @ 120 volts)
Weight 4.5 kg (9.9 lbs)
Speed Range 10,000 to 22,500 RPM (no load)
Quick Height Adjustment 70 mm (2.76")
Fine Height Adjustment 8 mm (0.31")
Maximum Bit Diameter 63 mm (2.5")
Collet Sizes 1/2-in. and 8mm Standard
1/4-in. and 3/8-in. Optional
Certifications IEC 745, UL745, CSA C22.2/745
All metric dimensions are binding.
