5.5 Power-on and COMRESET

C141-E224

5-157

Device TX
(Host RX)

Host TX
(Device RX)

Host/device

on

Host

ComReset

Host

releases

ComReset

Host

calibrate

Host

ComWake

Host

releases

ComWake

Host

Align

Host

data

Device

ComInit

Device

releases

ComInit

Device

Calibrate

Device

ComWake

Device

Align

Device

data

Figure 5.19 COMRESET sequence
