Fisher-Price B8776 - Manual (Page 2)

Seat
Key Frame
2 Pedals
2 Fork Covers
Front Wheel
Pedal Axle
Fork
Handlebar Back
Straight
Axle
2 Bushings
2 Wheel Hubs
2 Wheel Caps
#8 x 2 1 /
4
" Screw - 1
Note: Some parts shown are assembled
to both sides of the trike.
Parts
2
IMPORTANT!
• Please save all packaging material until assembly is
complete to ensure that no parts are discarded.
• Please wipe each part with a clean, dry cloth
before assembly.
*We’ve included one extra .354" cap nut for your convenience.
Note: Tighten and loosen the screws with a Phillips screwdriver.
Do not over-tighten the screws.
4 Pedal Hubs
WARNING CAUTION
To avoid serious injury:
• Adult supervision is required.
• Never use near cars and other motor
vehicles, near streets, steps, sloped drive-
ways, hills, roadways, alleys, swimming
pool areas or other bodies of water.
• Always wear shoes or sneakers.
• Never allow more than one rider.
This product contains small parts
in its unassembled state.
Adult assembly is required.
#8 x 3 /
4
" Screw - 6
2 Rear Wheels
Part not shown: Label Sheet
ALL SHOWN ACTUAL SIZE
Handlebar Front
.354" Cap Nut - 2*
.354"
