6
TABLE OF CONTENTS A
H7332pr-0920
TM
6
PARTS PICTURE D
2
4
8
6
9
15
1 Vehicle
2 Cowling
3 Seat
4 Wheel - 4
5 Hubcap - 4
6 Cap Nut - 5
7 Steering Column
8 Handlebar Neck
9 12 Volt Battery
10 12 Volt Charger
11 Microphone
12 Rear Wheel Driver - 2
13 Grip - 2
14 Handlebar Cover - Front
15 Handlebar Cover - Back
16 Steering Bushing
17 Handlebar
18 Rear Axle
Parts Not Shown
Label Sheet
19 Round Bushing - 2
20 #10 Lock Nut - 3
21 #10 x 1 5 /
8
" Screw - 2
22 #6 x 1" Screw - 6
23 #6 x 1 /
2
" Screw - 2
24 7 /
16
" Washer - 4
25 #10 x 3 /
4
" Screw - 1
26 Cap Nut Assembly Tool
10
5
1
14
16
12
Note: Some parts are assembled on both sides of the vehicle. This illustration shows assembly on right side only.
12-VOLT
CHARGER
18
6
5
4
19
24
24
6
7
25
20
21
22
23
22
11
22
13
17
20
3
26
20
