11 00989pr-1056
BATTERY INSTALLATION
IMPORTANT! Use only a Power Wheels ® 12 volt battery.
Use of any other battery will damage your vehicle.
• Press the tab under the back edge of the seat and lift
to remove the seat.
• Lift the battery retainer to access the battery compartment.
• Place the battery upright in the battery compartment.
• Plug the motor harness connector into the battery.
Push firmly.
Power Wheels ®
12 Volt Battery
Motor Harness
Connector
• Carefully lower the battery into the battery compartment.
The battery retainer slides over the battery to secure it.
1
2
3
Seat
4
Battery Retainer
Battery
Retainer
• Fit the tab at the front of the seat into the slot below
the drive buttons A .
• “Snap” the tab at the back of the seat into the slot
near the rear of the vehicle B .
Seat
Drive Buttons
A
B
