Furuno 1712 User Manual
Page 12
6
200
KNOB
BOLT
HANGER
200
12
11
*
SERVICE
CLEARANCE
4-
φ
6
FIXING
HOLES
93
80
*
70
*150
All dimensions
in millimeters
209
DUMMY FILM
Cover unused
knob bolt holes
with dummy film
(supplied).
OVERHEAD MOUNT
TABLETOP
MOUNT
CUTOUT SIZE
FOR PANEL
MOUNTING
192
192
Confirm the anti-vibration pad are
attached at both side of the hanger.
HARD
COVER
Figure 12 Mounting dimensions of display unit
