SP - 1
SPECIFICATIONS OF COLOR LCD SOUNDER
FCV-600L
This equipment is a dual-frequency (50/200 kHz) color LCD video sounder which has a large variety of
functions, all contained in a splash-proof rugged plastic case that is compact to fit small boats.
1. GENERAL
(1) TX Frequency
50 kHz/200 kHz
(2) Output Power 350 Wrms
(3) TX Rate 1500 pulse/min max.
(4) Pulselength 0.125 to 3.0 ms
(5) Sensitivity 15 dB µ V
(6) Transducer Dual-frequency one-mold type
2. DISPLAY UNIT
(1) Display Mode
5.6 inch color TFT LCD
(2) Echo Color 16 colors (including background color) according to echo intensity.
Marks are indicated in 8 colors. Monochrome display is also available.
(3) Display Mode Normal mode (high frequency / low frequency), Dual-frequency,
Zoom, Data, Graphic
(4) Zoom Display Marker zoom, Bottom zoom, Bottom-lock expansion
(5) Basic Range
Range No. Indication
Unit
1 2 3 4 5 6 7 8
Setting Range
Meters 5 10 20 40 80 150 200 500 2～500
Feet 15 30 60 120 200 400 600 1500 7～1500
Fathom 3 5 10 20 40 80 100 250 1～250
Passi/Braza 3 5 10 30 50 100 150 400 1～400
(6) Range Shift 0～300 m, 0～1000 ft, 0～150 fa or 0～200 p/b
(7) Zoom Range Bottom-lock expansion: 5 m or 10 m
Marker/Bottom zoom: from 2 m to 300 m
(8) Display Advance Speed 7 steps (Lines/TX: Freeze, 1/16, 1/8, 1/4, 1/2, 1/1, 2/1)
(9) User Setting Interference reduction, Clutter level, Alarm zone, Hue Setting,
Sensitivity adjustment
