2
1.2 Indications, Markers
The figure below shows all indications and markers which may appear in the normal display.
The combination displays (normal display plus marker or zoom display) may additionally dis-
play the zoom marker.
Water
temperature*
Speed*
Noise Limiter
Transducer frequency
Alarm icon
Active alarm
Range scale
Variable range
marker (green)
w/depth readout
Depth
Color
bar
Water temperature
scale*
Minute marker
(yellow, blue,
30 sec. each)
Nav data*
(DEMO)
Demonstration
mode
Alarm zone
marker
35
°
15.000’ N
135
°
07.500’ E
22.6
°
C 12kt NL1 200k F/NM
0
20
40
60
80
49.6
39.8
30
10
Water temperature
marker (orange)*
* Requires appropriate sensor.
0
20
All indications and
markers are displayed
in white unless
noted otherwise.
Figure 1-2 Indications
