FS-8700-113 Profibus DP Slave Driver Manual Page 3 of 13
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
PROFIBUS DP SLAVE DESCRIPTION 1
The FieldServer Profibus DP Slave driver can be used to emulate a single Slave station on a Profibus network. DP
Masters can open a connection of up to 244 Bytes of Input and 244 Bytes of Output data, but not exceeding a
combined total of 416 Bytes to the FieldServer. The FieldServer can be added to the Profibus network with the use
of the supplied GSD file for the ANYBUS card. Connection to the Profibus network is via a DB9 port on the
ANYBUS card.
1.1 Max Nodes Supported
FieldServer Mode Nodes Comments
Server
1 The FieldServer can only emulate one Profibus DP Slave station
DRIVER SCOPE OF SUPPLY 2
2.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies PART # Description
52201
Profibus Connector
FS-8915-32 Adapter Card, Anybus-S Profibus DP
2.2 Additional files required for the Driver
Filename Comments
Config.csv
1
Template loaded if no custom configuration ordered, otherwise Custom configuration loaded.
"Anybus gsd
file"
2
The Anybus template gsd file is supplied with the FieldServer and needs to be built up for the
particular application by the Master configuration software
2.3 Provided by the Supplier of 3
rd
Party Equipment
2.3.1 Required 3 r d Party Software
Profibus Network Configuration Tool
2.3.2 Required 3 r d Party Configuration
Connection to a properly terminated Profibus network.
1 Always Loaded By FieldServer Technologies
2 External Application
