Figure 3 input/output connections - 1524, Table 3 1524 input/output connections, T1 t2 – Fluke 1523 User Manual
Page 18
1523, 1524 Thermometer Readout
Setup
10
SAVE
NEXT
HOME
LOG
RESET
ENTER
RECALL
HOLD
STATS
°
C
°
F
SETUP
TREND
mV
RS
232
12
V DC
30
V MAX
T1
T2
1524
CALIBRATION
THERMOMETER
READOUT
Figure 3 Input/Output Connections - 1524
1524 Input/Output Connections
Table 3
No
Name
Description
1
Serial
Serial interface connector
2
Connector, T1
Sensor Connector, Channel 1
3
Connector, T2
Sensor Connector, Channel 2
4
Power
External Power adapter connection
1
2
4
3
