2 quick start, 1 setup, Figure 2 input/output connections - 1523 – Fluke 1523 User Manual
Page 17: Table 2 1523 input/output connections, Quick start 2, Setup 2.1
Quick Start
Setup
9
Quick Start
2
Setup
2.1
SAVE
NEXT
HOME
ENTER
RESET
TREND
RECALL
HOLD
STATS
°
C
°
F
SETUP
mV
RS
232
12
V DC
30 V MAX
1523
CALIBRATION
THERMOMETER
READOUT
Figure 2 Input/Output Connections - 1523
1523 Input/Output Connections
Table 2
No. Name
Description
1
Serial
Serial interface connector
2
Connector, T1
Sensor Connector, Channel 1
4
Power
External Power adapter connection
1
2
4
