6
Part II: System Setup
SYSTEM SETUP
Your Faria Antares unit should already have been setup by either the boat
manufacturer or by your dealer. Check with your dealer before beginning the System
Setup process.
In order to get the optimal performance out of your Faria Antares unit, the
following steps are recommended. Some of the information needed to complete the setup
process will be contained in your boat owner’s manual. Be sure to have your boat
owner’s manual available before beginning the Antares setup process.
To begin, use the left or right arrows on the navigation pad to highlight the
Antares Menu Screen on the screen indicator bar located at the bottom of the
screen. Then use the down arrow on the navigation pad to scroll down to SYSTEM
SETUP and press
.
Step 1: INPUT SETUP
Input Setup will allow you select which analog senders are connected to your
Antares unit.
To activate or deactivate a sender, use the left or right navigation buttons to select
either TANK 1, TANK 2, TRIM / TANK 3, AIR TEMP or SPEED SOURCE. Once the
desired selection is highlighted, press
. Now use the up or down navigation buttons
to highlight the desired setting, then press . The icon on the Save Changes bar
will automatically highlight. If your changes are correct, press to save.
will appear to confirm that changes have been saved. If the changes are
not correct, use the navigation pad to highlight and press .
will appear to confirm that the changes have not been saved. Refer to the list of available
INPUTS on the next page for further instructions.
Use the navigation pad to highlight INPUT SETUP, then
press
.
Use the navigation pad to highlight SYSTEM SETUP,
then press
.
