9
Step 3: Depth Setup
Depth Setup will allow you to set the shallow water alarm, set the deep water alarm, and
set the keel offset.
Note: A digital depth transducer must be installed on your boat for the depth
option to work. Refer to your owner’s manual to determine if there is a transducer
installed. Your Antares will automatically recognize if a compatible digital depth
sounder is installed.
Use the up or down arrows on the navigation pad to highlight the desired option, then use
the left or right arrows on the navigation pad to make the appropriate changes.
Once you have adjusted all the options to the desired settings, press
. The
icon on the Save Changes bar will automatically highlight. If your changes are
correct, press
to save.
will appear to confirm that the changes have
been saved. If the changes are not correct, use the navigation pad to highlight
and
press
.
will appear to confirm that the changes have not been
saved.
Once you have saved all the appropriate settings, press
to return to the SYSTEM
SETUP menu.
YOU ARE NOW FINISHED WITH THE SETUP PROCESS. PRESS
TO
RETURN TO THE MAIN MENU SCREEN. SIMPLY USE THE NAVIGATION PAD
TO MOVE YOUR WAY THROUGH THE ANTARES DISPLAY SCREENS. YOU
ARE NOW READY TO HEAD OUT ON TO THE WATER.
Use the navigation pad to highlight DEPTH SETUP, then
press
.
