2-13
ITEM
PART #
COMPONENT
Complete Box Assemblies
100-120V (Domestic)
106-4125
Full-vat with Melt Cycle
106-4129
Dual-vat with Melt Cycle
120V (Domestic)
106-4126
Full-vat with Melt Cycle
106-4130
Dual-vat with Melt Cycle
208-240V (Domestic)
106-4127
Full-vat with Melt Cycle
106-4131
Dual-vat with Melt Cycle
208-250V (Export)
106-4128
Full-vat with Melt Cycle
106-4132
Dual-vat with Melt Cycle
106-4134
With Mechanical Melt Cycle Timer (CE)
Components
1
200-6970
Component Box
2
200-6855
Bracket, Component Box Gap
*
200-6956
Cover, Component Box Hole (see illustration on Page 2-10)
3
810-0045
Bushing, .875”
4
826-1546
Melt Cycle Kit with Mechanical Timer
5
810-1164
Terminal Block, 1 Plc. Screwless Terminal
6
810-1168
Terminal Block, Screwless End
7
816-0217
Insulating Paper
8
806-9613
Board, Melt Cycle Timer
Wiring
*
WIR0161
Component Shield (with Melt Cycle) Wiring (DV)
*
WIR0164
Component Shield (with Melt Cycle) Wiring (FV, 240V and below)
*
WIR0165
Component Shield (Std.) Wiring (FV, 208-250 Export only)
*
WIR0148
Component Shield (with Mechanical Timer) Wiring
9
Transformers
807-2176
100-120V/12V & 24V
807-0855
120V/12V
807-0800
120V/24V
807-0680
208-240V/24V
807-1999
208-250V/12V & 24V
10
826-1365
Screw, 6-32 x ⅜ Trussed Slotted Head (pkg. of 25)
11
826-1359
Screw, 4-40 x ¾ Pan Slotted Head (pkg. of 25)
* Not illustrated.
