3
FTP-632MCL101/102/353/354
For head
24 VDC
±
5% 2.3A
(24V Rav1500
Ω
, 25%printing ratio)
For printer motor 24VDC
±
5% 1A maximum
For cutter motor --- 24VDC
±
5% 1A maximum
For logic 5VDC
±
5% 0.5 A maximum
Printer Mechanism 108 (W)
×
48 (D)
×
20 (H) mm ---
Dimensions
Mechanism with cutter --- 117 (W)
×
57 (D)
×
38 (H) mm
Interface board 131 (W)
×
89 (D)
×
24 (H) mm
Weight Printer Mechanism Approximately 94g ---
Mechanism with cutter --- Approximately 340g
Life Head Pulse durability: 1
×
10 8 pulse/dot (using Fujitsu Components' standard
driving method)
Wear resistance: 50 km (at 25% print ratio)
Cutter ---- 500,000 times minimum
Operating temperature +5 to +40
°
C (Guarantee, but can operate between 0
°
C to +50
°
C)
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60
°
C (excluding paper)
Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor
Detection Paper out/Mark detect By photointerrupter
Head release By slide switch
2 color paper (blue/black) PB770 (Mitsubishi paper)
(red/black) PB670 (Mitsubishi paper)
High sensitivity paper TF50KS-E4 (Nippon paper)
Standard paper TF60KS-E (Nippon paper), FTP-030P0104(80mm)
PD150R (Oji paper), FTP-030P0701(80mm)
Medium term paper TP60KS-F1 (Nippon paper), FTP-030P0102(80mm)
PD170R (Oji paper)
P220VBB-1 (Mitsubishi paper)
PD160R-N (Oji paper)
Long term paper AFP-235 (Mitsubishi paper)
TP50KJ-R (Nippon paper)
HA220AA (Nippon paper)
Specifications Item
(Continued)
Power
supply
Environmental
conditions
Part number FTP-632MCL101/102 FTP-632MCL353/354
Recommended
thermal sensitive
paper
