MB15E07SL
18
3.
Do output current
V
DO
- I
DO
V
DO
- I
DO
Charge pump output voltage V
DO
(V)
Charge pump output current I
DO
(mA)
Charge pump output voltage V
DO
(V)
Charge pump output current I
DO
(mA)
10.00
–10.00
0
.6000/div
4.800
2.000
/div
0
Ta = +25
°
C
V
CC
= 3.0 V
Vp = 3.0 V
I
DOH
I
DOL
10.00
–10.00
0
.6000/div
4.800
2.000
/div
0
Ta = +25
°
C
V
CC
= 3.0 V
Vp = 3.0 V
I
DOH
I
DOL
1.5 mA mode
6.0 mA mode
