All Shown Actual Size
Not Shown: Label Sheet, Literature Bag
1 1 /
2
" Screw – 2
Cap Nut – 8*
7 /
16
" Washer - 6*
Radio Knob - 2
6 Volt Battery - 2
Hex Bushing - 4
Cap Nut
Installation Tool
Round Bushing - 2
#8 x 3 /
4
" Screw – 19*
Microphone
12-Volt Charger
Key Assembly
WARNING PREVENT FIRE • Do not bypass a Power Wheel • Use only a Red Power Wheels • Never modify the electrical
WARNING PREVENT FIRE • Do not bypass a Power Wheel • Use only a Red Power Wheels • Never modify the electrical
Lock Nut - 2
*For your convenience, extra washers, screws and cap nuts have been included.
5
Parts
Handlebar Housing -
Top Half
Front Fairing
Handlebar Housing -
Bottom Half
Handlebar
Sound Box
