6-16 2. Main Menu Screen
2-1. Card Recorder Menu Screen
When the [Card Recorder Menu] switch on the “Card Menu” screen is pressed, the following “Card
Recorder Menu” screen appears.
This screen is used to transfer screen data between the UG230 and a memory card.
The procedure for transferring data is described below.
1. Connecting the UG00P-MR
Connect the UG00P-MR using the attached cable to the MJ port that is displayed in the “Port
Selection” field.
• MJ1: Connect the UG00P-MR to the MJ1 port. Normally MJ1 is
selected.
• MJ2: Connect the UG00P-MR to the MJ2 port. Only when
[Memory Card] is selected for [Modular Jack 2], “MJ2” is
indicated in the “Port Selection” field.
2. Mounting the Memory Card
Insert a memory card in to the card recorder.
3. Memory Card Information
Press the [Modular Jack MJ1] switch.
The memory card information contained in the inserted memory card is indicated.
To move back to the previous screen, press the [Close] button.
