FUNAI SV2000 WV20V6 - Manual (Page 10)

10 EN
Functional overview (cont’d)
Before you start
22. SETUP button (DVD/VCR)
Press to display the Setup menu.
During DVD playback, press and
hold for more than 3 seconds to
switch the progressive scanning
mode to the interlace mode.
23. CLEAR button (DVD/VCR)
• DVD mode
Press to clear the password
entered, to cancel the
programming for CD, to clear
the highlighted marker number
in the Edit menu or to clear the
program once entered in the Timer
Programming list, etc.
• VCR mode
Press to reset the tape counter.
24. OK button (DVD/VCR)
Press to confirm or select menu
items.
25. RETURN button (DVD/VCR)
Press to return to the previously
displayed menu screen.
26. DVD REC button (DVD)
Press to activate the remote
control in DVD mode (refer to
page 11).
Press once to start a recording.
Press repeatedly to start the
One-touch Timer Recording.
27. DVD button
Press to activate the remote
control in DVD mode (refer to
page 11).
Press to select the DVD output
mode.
28. F.FWD D button (DVD/VCR)
• DVD mode
During playback, press to play
back in fast forward.
Or when playback is paused,
press to play back in slow
forward.
• VCR mode
Press to rapidly advance the
videotape or view the picture
rapidly in forward during playback.
29. PLAY B button* (DVD/VCR)
Press to start or resume playback.
30. NEXT G button (DVD)
During playback, press to skip to
the next chapter or track.
Or when playback is paused,
press to play back in forward step
by step.
31. PAUSE F button (DVD/VCR)
Press to pause playback or
recording.
32. SEARCH button (VCR)
Press to call up the index or time
search menu.
33. STOP C button (DVD/VCR)
Press to stop playback or
recording.
Press to exit from the title list.
34. AUDIO button (VCR)
During playback a HiFi videotape,
press to change the AUDIO OUT
setting “HIFI” and “MONO”.
9. REC MODE button (DVD/VCR)
Press to change the recording
mode.
10. REW E button (DVD/VCR)
• DVD mode
During playback, press to play
back in fast reverse.
Or when playback is paused,
press to play back in slow
reverse.
• VCR mode
Press to rewind the videotape
or to view the picture rapidly
in reverse during the playback
mode.
11. RAPID PLAY button (DVD)
During playback, press to
playback in a slightly faster/slower
speed with keeping the audio
quality.
12. PREV H button (DVD)
During playback, press to skip to
the previous chapter or track.
Or when playback is paused,
press to play back in reverse step
by step.
13. SLOW button (VCR)
During playback, press to view the
videotape in slow motion.
14. CM SKIP button (DVD)
During playback, press to skip to
the 30 second advanced point.
15. DUBBING button (DVD/VCR)
Press to start VCR to DVD (DVD
to VCR) duplication which you set
in the Setup menu.
16. ZOOM button (DVD)
During playback, press to enlarge
the picture on the screen.
17. TIMER SET button (DVD/VCR)
Press to set the unit in the timer
standby mode. In the timer
standby mode, press to cancel
the mode and to turn the unit on.
18. OPEN/CLOSE A button (DVD)*
• DVD mode
Press to open or close the disc tray.
19. TIMER button (DVD/VCR)
Press to display the Timer
Programming list.
20. CH K / L buttons (DVD/VCR)
• DVD mode
Press to change the channel up
and down.
• VCR mode
Press to change the channel up
and down.
Press to adjust the tracking during
playback or in slow motion of the
videotape. Also while playback is
in Still Mode, you can adjust the
picture blurred vertically.
21. VIDEO/TV button (DVD/VCR)
Press to select VIDEO or TV
position.
1. STANDBY-ON button
(DVD/VCR)
Press to turn on and off the unit.
2. Number buttons (DVD/VCR)
Press to select channel numbers.
Press to select a title / chapter /
track on display.
Also press to enter values for the
settings in the Setup menu.
Also press to start the index/time
search in VCR mode.
3. DISPLAY button (DVD/VCR)
Press to display the Display menu
on or off.
4. TITLE button (DVD)
Press to display the Title list.
5. DISC MENU button (DVD)
Press to display the Disc menu.
Press to change Original and
Playlist on the TV screen.
(VR mode only)
6. Cursor K / L / { / B buttons
(DVD/VCR)
Press to select items or settings.
7. VCR REC button (VCR)
Press to activate the remote
control in VCR mode (refer to
page 11).
Press once to start a recording.
Press repeatedly to start the One-
touch Timer Recording.
8. VCR button
Press to activate the remote
control in VCR mode (refer to
page 11).
Press to select the VCR output
mode.
STOP
STANDBY-ON
TIMER SET TIMER
PREV NEXT
OPEN/CLOSE
SPACE
1 2 3
4 5 6
7 8
0
9
CH
VIDEO/TV
SLOW
PAUSE
.@/: ABC DEF
GHI JKL MNO
PQRS
REC
DISPLAY
TUV WXYZ
DVD REC
REC MODE
ZOOM
SEARCH
VCR
SETUP
CM SKIP
RETURN DISC MENU TITLE
DUBBING
RAPID PLAY
CLEAR
OK
PLAY
AUDIO
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
14
28
29*
30
31
32
33
34
27
26
25
24
23
19
17
22
18*
20
21
Remote Control
(*) In DVD mode, the unit can also be
turned on by pressing these buttons.
