International Electrical Symbols
3
International Electrical Symbols
Table 1 lists the international symbols that appear in this document and on the Meter.
Table 1. Electrical Symbols
Symbol Description Symbol Description
B
AC (Alternating Current)
I
Fuse
F
DC (Direct Current)
T
Double Insulated
X
Hazardous voltage
W
Important Information; Refer to manual
N
Battery (Low battery when shown on the
display.)
J
Earth ground
~
Do not dispose of this product as unsorted municipal waste. Contact Fluke or a qualified recycler for
disposal.
Specifications
Accuracy is specified for 1 year after calibration at operating temperatures of 18 ° C to 28 ° C, with relative humidity at 0 % to 90 %. Extended
specifcifications are available at www.fluke.com.
General Specifications
Maximum voltage between any
terminal and earth ground ................................... 600 V
Surge Protection................................................... 6 kV peak per IEC 61010-1 600V CAT III,
Pollution Degree 2
W Fuse for A input (115 & 117 only):.................. 11 A, 1000 V FAST 17 kA Fuse (Fluke PN 803293)
Display ................................................................... Digital: 6,000 counts, updates 4/sec
Bar Graph: 33 segments, updates 32/sec
Temperature .......................................................... Operating: -10 °C to +50 °C
Storage: -40 °C to +60 °C
Temperature Coefficient ...................................... 0.1 x (specified accuracy)/ ° C (<18 ° C or >28 ° C)
Operating Altitude ................................................ 2,000 meters
Battery ................................................................... 9 Volt Alkaline, NEDA 1604A / IEC 6LR61
Battery Life ............................................................ Alkaline: 400 hours typical, without backlight
Safety Compliances.............................................. Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2 No 61010-1-04, UL 6101B
(2003) and IEC/EN 61010-1 2nd Edition for measurement Category III, 600 V, Pollution
Degree 2, EMC EN61326-1
Certifications......................................................... UL, P, CSA, TÜV, ; (N10140), VDE
IP Rating (dust and water protection)................. IP42
