Replaceable Parts
13
Replaceable Parts
Refer to Table 4 for all replacement part numbers and Figure 8 for part locations. Unless specified in the
“Model Number” column, all parts are for all units. To order replaceable parts, see the “Service Centers”
section of this manual.
Table 4. 50S and 50D Replaceable Parts
Item
Number Qty.
Fluke
Part
Number Description
Model
Number
1
1
1 778191
778209 MAIN PCA
MAIN PCA 50S
50D
2 1 696534 BATTERY, PRIMARY, 9V, 0-15MA All
3 4 832246 SCREW, PH, P, AM THD FORM, STL, 5-14, .750 All
4 1 519116 SCREW, PH, P, THD FORM, STL, 4-24, .250 All
5 4 448456 SCREW, PH, P, AM THD FORM, STL, 4-14, .375 All
6 1
1280490
1280483 CASE, TOP
CASE, TOP 50S
50D
7 1
1280766
1280753 CASE, BOTTOM
CASE, BOTTOM 50S
50D
8 1 646653 BRACKET, LCD All
9 1 1280151
1280160 MASK, BRACKET, FLUKE 50S
MASK, BRACKET, FLUKE 50D 50S
50D
10 1 745794 ISOTHERMAL BLOCK All
11 2 649632 CONNECTOR , ELASTOMERIC, LCD TO PWB, 1.900 L All
12 1 761924 BOTTOM SHIELD, MYLAR All
13 4 640565 FOOT, NON-SKID All
14 1 844340 LABEL, WINDOW All
15 1 791343 WINDOW, LCD (BLANK) All
16 1 742205
741314 LCD FLUKE-51, LCD, 5 DIGIT, TEMPERATURE, MULTIPLEXED
LCD FLUKE-52, LCD, 5 DIGIT, TEMPERATURE, MULTIPLEXED 50S
50D
Not shown
1
2
773135 THERMO COUPLE ASSY, T/C ASSY, K-TYPE, BEADED, MOLDED-PLUG
50S
50D
Not shown 1 1278540 MULTI-LANGUAGE, FLUKE 50S & 50D USERS MANUAL All
Not shown 1 890298 HOLSTER & FLEXSTAND ASSY, YELLOW All
