• Fit the wide notch in the side of a headlight lens under
the wide tab on a lens guard.
• Press firmly on the inside of the headlight lens to snap it
into the lens guard.
• Repeat this procedure to assemble the other headlight
lens to the remaining lens guard.
Lens
Wide
Notch
Wide Tab
Lens Guard
10
Assembly
9
Steering Wheel
• Fit the steering wheel cap into the center of the steering
wheel with the screw holes aligned.
• Insert two #8 x 1" screws as shown.
• Tighten the screws with a Phillips screwdriver.
Do not over-tighten.
#8 x 1" Screws
Steering Wheel
Cap
12
• Fit the lens tabs on the back of a lens assembly into the
headlight slots in the grille.
• Press firmly to snap the lens assembly into the grille.
• Repeat this procedure to snap the other lens assembly
into the grille.
Grille
Tabs
Slots
11
8
• Turn the vehicle body upright.
• Position the steering wheel so that the spokes form a
“Y” as shown. The tab on the steering wheel stem
should face up.
• Fit the steering wheel onto the steering column.
• Fit a cap nut onto the end of the steering column.
• Tap the cap nut with a hammer to secure it on the
steering column.
Helpful Hint! You may want the help of another person
to support the steering column while you tap the cap nut
with the hammer.
Steering Wheel
Cap
Nut
Steering
Column
“UP”
Tab
