• Locate the battery compartment door on the back of
the radio.
• Loosen the screw in the battery compartment door using
a Phillips screwdriver and lift to open.
• Insert three “AA” (LR6) alkaline batteries as indicated in
the battery compartment.
• To replace the battery compartment door, fit the tabs
on the door into the slots on the radio. Lower to close.
Tighten the screws with a Phillips screwdriver.
Do not over-tighten.
Battery
Compartment
Radio
Slots
Tab
Tab
Battery
Compartment
Door
3
• Position the dash on the vehicle body. Make sure the
holes in the dash tabs align with the holes in the vehicle
body and that the channel cover is captured by the dash.
• Insert two #10 x 1" screws through the holes towards the
rear of the dash (closest to the hood area) and into the
vehicle body
.
• Insert two #10 x 1 /
2
" screws through the holes towards the
front of the dash (closest to the passenger compartment)
and into the vehicle body
.
• Tighten each screw with a Phillips screwdriver.
Do not over-tighten.
Assembly
Do not omit any steps. Please set aside at least 60 minutes for assembly.
F
1
10
2 1
1
2
1
2
Dash
Channel
Cover
Tab
Please Note:
• Do not mix old and new batteries.
• Do not mix different types of batteries: alkaline, standard
(carbon-zinc) or rechargeable (nickel-cadmium).
• Remove batteries during long periods of non-use.
Always remove exhausted batteries from this product.
Battery leakage and corrosion can damage this product.
Dispose of exhausted batteries safely.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to be recharged.
• Only batteries of the same or equivalent type, as
recommended above, are to be used.
• If removable rechargeable batteries are used, they are
only to be charged under adult supervision.
• Rechargeable batteries are to be removed from this
product before they are charged.
• Battery chargers used with toys must be examined
regularly for damage to the cord, plug, enclosure and
other parts. In the event that such damage is found, the
toy must not be used with the battery charger until the
damage has been repaired.
2
• Fit the tabs on the radio into the slots in the dash.
• Insert two #8 x 1" screws through the holes in the top of
the radio and into the dash.
• Tighten the screws using a Phillips screwdriver.
Do not over-tighten.
1.5V x 3
“AA” (LR6)
#8 x 1" Screws
