Parts
3
Front Base
Rear Base
Housing
2 Rear Legs
(Shorter)
Motor Housing
Seat with Restraint
2 Seat Tubes
Bracket
(with M4 Lock Nuts)
Seat Wire
2 Seat Wire
Caps
2 Accessory Bins
Pad
Sound ‘n
Lights Tray
Mirror Base
Remote Control
and Holder
(with M4 Lock Nut)
Tray
2 Front Legs
(Longer)
M4 Screw - 4
Shown Actual Size
Note: Tighten or loosen all screws and bolt with a Phillips screwdriver. Do not over-tighten the screws.
#8 x 1 3 /
8
" Screw - 10
Shown Actual Size
#6 x 5 /
8
" Screw - 4
Shown Actual Size
M4 Bolt - 1
Shown Actual Size
