Frymaster 2836 User Manual
Page 44
2-20
2.9 Frypot and Related Components
2.9.1.1 Frypot and Drain Valve Components
Item Part
Number
Description
*
106-5916
Frypot Assembly, FP14 (FP28DV) 55lbs
(no float switch)
106-4198
Frypot Assembly, FP28 110 lbs
(no float switch)
106-4203
Frypot Assembly, FP36S 160 lbs
(no float switch)
1
823-4815
Frypot W/A, Wal-mart FP28FV110#
(no float switch)
823-4816
Frypot W/A, Wal-mart FP36FV 160#
(no float switch)
*
823-5597
Frypot W/A, Wal-mart FP14 (FP28DV) 55#
(no float switch)
2
813-0165
EL, ST ½” NPT 90deg BM
3
210-6765
Bracket, FP28/36 Lower Spring
4
806-8035
Thermostat Assembly, 435° Hi-Limit
5
826-1374
Screw, #10- ½ ” Hex Washer HD NP (Pkg. of 25)
*
810-0297
Spring Element Lift Blue 110# FP28
*
810-1546
Spring Element Lift Green 160# FP36
6
810-1668
Adapter, Male 5/8" O.D. X ½”
7 106-3756
Valve
Assembly, FP28/36 Frypot Drain
(Use 106-5917 for FP14 (FP28DV))
8
816-0405
Sleeve, Drain Handle Red Plastic
9
210-7077
Handle, Drain Valve
(Use 230-0892 for FP14 (FP28DV))
10 200-1617
Washer,
Drain Microswitch K118G
11
200-5694
Cover, Switch Drain FPP
12
200-6345
Bracket, Drain Valve Mounting
13 106-3745
Bracket
Assembly
14
807-2103
Switch, CE Micro Straight Lever
15
826-1366
Nut, 4-40 KEPS HEX w/external Tooth (Pkg. of 25)
16
810-2783
Valve, 1½” Full Port Drain
17
816-0220
Insulation, RF Switch
18 816-0544
O-Ring,
Seal
* Not Illustrated
