M E D T E S T E R 5 0 0 0 C F I E L D U P G R A D E I N S T A L L A T I O N I N S T R U C T I O N S

3

Module and Upgrade Parts

Check that you have received the following parts with your module or upgrade:

Firmware Upgrade

2 IC RAM chips (40-pin devices, labeled U20 and U21)

Modules 2, 3, 5, 6, 8, 9, 10, 11, 12, 13, and 14

Installation disk, 1 for each module

Module 4 Expanded Memory

Installation disk

IC RAM (32-pin device without label)

Module 7 medCheck

Installation disk

4 IC RAMs (32-pin device without label)

Note

If you are upgrading your medTester 5000C firmware, and your
medTester currently includes medCheck, then your medCheck
Module does not include the four (4) RAM ICs because they are
already in your medTester. However, you may have received the
installation disk in the event you need to reinstall it.

Required Equipment for Upgrade/Modules

To install a medTester 5000 firmware upgrade or to enable a medTester 5000C
module, you need:

For a -medTester 5000C Firmware Upgrade or to install modules that contain ICs
(integrated circuits)

a knife (not needed if the quality sticker has previously been removed);

a Phillips screwdriver, #2-type;

an IC removal tool (not needed for instruments with lever handle IC
sockets).
