SP - 1
SPECIFICATIONS OF COLOR LCD SOUNDER
FCV-582L
This equipment is a dual-frequency (50/200 kHz) color LCD video sounder which has a large variety of
functions, all contained in a splash-proof rugged diecasting aluminum case that is compact to fit small
boats.
1. GENERAL
(1) Transmit Frequency 50 kHz/200 kHz
(2) Output Power 600 Wrms
(3) Tx Rate 1500 pulse/min max.
(4) Pulselength 0.13 to 3.6 ms
(5) Transducer Dual-frequency one-mold type
2. DISPLAY UNIT
(1) Indication System 6.5-inch color TFT LCD
(2) Echo Colors 8 or 16 colors depending on echo intensity.
Monochrome presentation is also available.
(3) Display Mode Normal (high/low), Combination display, Marker zoom, Bottom zoom,
Bottom-lock expansion
(4) Alphanumeric Data Digital display of water depth, *Water temperature,
*Ship’s speed/position data
*: Speed/temperature sensor is required.
(5) Basic Display Range
Range Unit
1 2 3 4 5 6 7 8
Range Setting
Meters 5 10 20 40 80 150 300 800 2 to 800
Feet 15 30 60 120 200 400 1000 2500 7 to 2500
Fathoms 3 5 10 20 40 80 150 400 1 to 400
Passi/Braza 3 5 10 30 50 100 200 500 1 to 500
(6) Range Shift 0 to 800 m, 0 to 2500 ft, 0 to 400 fa or 0 to 450 p/b
(7) Expansion Range Bottom lock expansion: 5/10m
Target lock expansion: 2 m to 800 m
(8) Picture Advance Speed 7 steps (Lines/Tx: freeze,1/16,1/8,1/4,1/2,1/1,2/1)
(9) User Setting Interference rejecter, Clutter, Alarm, Sensitivity, Hue level, Sensitivity
