FTP-627MCL401/601
n ParT NuMberS
n SPeCiFiCaTiONS
Part Number
Easy Load Model with low profile cutter FTP-627MCL401
FTP-627MCL601
LSI for driving MCL401 FTP-627CU301R
MCL601 FTP-627CU601R
Interface
board for
Mech/Cutter
Cutter
supported
MCL401 FTP-627DSL291R Parallel (Centronics) /Serial (RS-232C)
MCL601 FTP-627DSL601R, Serial (RS-232C) / USB
MCL401 FTP-627DSL603R (USB)
FTP-627DSL605R Serial (RS-232C)
MCL601 FTP-627DSL613 R (USB)
FTP-627DSL615 R Serial (RS-232C)
Interface
cables
Parallel (Centronics) FTP-628Y202
Serial (RS232C) FTP-628Y302
USB FTP-629Y301
Power
cables
Logic FTP-629Y401
Head, motor FTP-629Y601
Part number FTP-627MCL401/601
Printing method Thermal-line dot method
Dot structure 432 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 54 mm
Number of columns ANK 36 columns/line
(maximum 12/24 dot font)
Paper width 58 mm
Paper thickness 60 to 85 µm (some paper in this range may not be
used because of paper characteristics)
Printing Speed Maximum 100mm/sec. (800 dot line/sec.)
Maximum 150mm/sec. (1,200 dot line/sec.)
Alphanumeric, kana: 159 types
International characters: 195 types
JIS Kanji (Kanji CG loaded board): about 6800 types
2 × 24 dots, (1.5 × 3.0 mm), 36 columns: ANK
24 × 24 dots, (3.0 × 3.0 mm), 18 columns: ANK
8 × 16 dots, (1.0 × 2.0 mm), 54 columns: ANK
6 × 16 dots, (2.0 × 2.0 mm), 27 columns: ANK
Specifications Item
Character types
Character, dimensions (W×H), number
of columns
MCL401
MCL601
