DEAN MILLIVOLT GAS FRYERS (CE)
CHAPTER 3: INSTALLATION INSTRUCTIONS
3-13
3.8 Gas Conversion Components
Use the following components to convert from natural gas to propane and vice-versa. See Section
3.6 for orifice quantities required for conversion. NOTE: On SR42 units built after 4/07, use Kit
826-1817 to convert from natural to propane. Use kit 826-2017 to convert from propane to natural.
The kits include bushings to accommodate the smaller orifice port on the newer fryers.
Natural Gas to Propane Components Propane To Natural Gas Components
REF DESCRIPTION REF DESCRIPTION
810-2400 Pilot orifice (LP) 810-0811 Pilot orifice (26N)
810-2059
Burner orifice
(diameter: 1.51 mm) †
810-2060
Burner orifice
(diameter: 2.40 mm) †
New Rating
Label
Contact factory at time of
conversion. PN 802-2144
New Rating
Label
Contact factory at time of
conversion. PN 802-2144
† Burner orifices listed are for fryers operating at altitudes of 610 meters or less. For
altitudes greater than 610 meters, contact the factory for the correct orifice size.
3.9 Electrical Connections
Fryers without built-in filtration do not require electrical connection. Fryer systems with built-in
filtration when installed must be electrically grounded in accordance with local codes, or in the
absence of local codes, with the appropriate national standards.
WARNING
Fryers with built-in filtration systems are equipped with a three-prong (grounding)
plug for protection against shock hazard. It should be plugged directly into a
properly grounded, three-prong receptacle. DO NOT CUT, REMOVE, OR
OTHERWISE BYPASS THE GROUNDING PRONG ON THIS PLUG.
For fryers with built-in filtration systems: The rating plate and wiring diagram are located on the
inside front door panel. Built-in filtration systems are equipped with 120VAC single-phase 60-hertz
system (Domestic), or 230VAC single-phase 50-hertz system (International/CE). Do not cut or
remove the ground prong from the power cord plug.
DANGER
This appliance requires electrical power (built-in filtration systems only) for
operation. Place the gas control valve in the OFF position in case of a prolonged
power outage. Do not attempt to operate this appliance during a power outage.
