DEAN MILLIVOLT GAS FRYERS (CE)
CHAPTER 3: INSTALLATION INSTRUCTIONS
3-10
3.6 Gas Inputs (cont.)
A. Adjustments for different gases are as follows (cont.):
MODEL*
ORIFICE
SIZE (MM)
GAS TYPE
GAS PRESSURE AT
REGULATOR
BURNER
MARKING
PILOT
MARKING
SR 52GM
SM 50GM
2,40
2,40
1,51
G20
G25
G31
12,0
17,5
22,0
4,8
7,0
8,8
Blue
Blue
Red
26N
26N
16LP
SM 35GM
SR 38GM
SR 42GM
2,40
2,40
1,51
G20
G25
G31
12,0
17,5
22,0
4,8
7,0
8,8
Blue
Blue
Red
26N
26N
16LP
SM 20GM
2,40
2,40
1,51
G20
G25
G31
12,0
17,5
22,0
4,8
7,0
8,8
Blue
Blue
Red
26N
26N
16LP
*SR prefix- Super Runner Series
*SM prefix- Super Marathon Series
*GM suffix- gas millivolt system with no electrical supply connections required
(1) The Netherlands (NL) only.
NOTE: Outlet gas pressure must be adjusted strictly within the above requirements 5 to 10 minutes
after the appliance is operating.
* For controls and adjustments, please refer to the gas valve illustration on page 3-12. (Pilot Flame
Adjustment: Turn the pilot adjustment screw clockwise/counter-clockwise until the desired flame-
volume is achieved).
WARNING
If gas odors are detected, the gas supply
MUST be shut off at the main shut-off
valve, and the local gas company or authorized service agency contacted for
immediate service.
