5. CUSTOMIZING YOUR UNIT
5-18
Contents of C-MAP chart details menu (continued from previous page)
Settings Default Setting Settings Default Setting
Item Description
MODEL1722C series MODEL1722 series
Chart Generation Chart generation
category icons
Plotter/Overlay,
Plotter, Off Plotter/Overlay On, Off On
New Object New object
category icons Plotter/Overlay,
Plotter, Off Plotter/Overlay On, Off On
Complex Object
Icon Single or multiple
icon for object
composed of
several icons Multiple, Single Multiple Multiple, Single Multiple
Information Level Basic or detailed
data for objects
Basic, Detailed Basic Basic, Detailed Basic
Bathymetric Line Plotter/Overlay,
Plotter, Off
Plotter/Overlay On, Off On
Spot Sounding Plotter/Overlay,
Plotter, Off Plotter/Overlay On, Off On
Bottom Type Plotter/Overlay,
Plotter, Off Plotter/Overlay On, Off On
Depth Areas
Limit 0-99999ft
(m, fa, PB) 20,164ft (6, 50m,
3, 27 fa, 4, 30PB) 0-99999ft
(m, fa, PB) 20ft (6m, 3fa,
4PB)
DEPTH INFO
(soft key)
See illustration
on next page
Bathymetric
Range 0-99999ft
(m, fa, PB) 0-33ft (0-10m,
0-6fa, 0-6PB) 0-99999ft
(m, fa, PB) 0-33ft (0-10m,
0-6fa, 0-6PB)
Settings description
Basic: Shows basic characteristics of objects.
Detailed: Shows detailed characteristics of objects.
Multiple: Shows multiple icons for complex objects
Off: Turns item off.
On: Turns item on.
Plotter: Shows item on plotter display:
Plot/No Sector: Sector not shown on track display.
Plotter/Contour: Shows contour on track display.
Plotter/Overlay: Shows item on plotter and overlay displays.
Single: Shows single icon for complex objects.
