J4394pr-0921 17
• Insert a screw into the right side mirror and tighten.
• Repeat this procedure to assemble the left side mirror.
• Fit the steering wheel cap onto the center of the steering wheel.
• Insert two screws into the steering wheel cap and tighten.
34
36
• Position the right side mirror with the recessed area facing up,
as shown.
• “Snap” the right side mirror onto the post on the right side of
the vehicle.
• Turn the mirror upright.
37
Steering
Wheel Cap
Side Mirror
Recessed Area
Post
Right Side Mirror
• Pull up on the steering wheel to be sure it is assembled correctly.
If you can remove the steering wheel, you have not inserted
the pin properly. Please review assembly steps 32-34 and
re-assemble the steering wheel.
35
INSIDE VIEW
SIDE VIEW
