J4394pr-0921 16
• Align the tabs on a hubcap with the slots in a wheel. “Snap” a
hubcap into the center of each wheel.
• Turn the vehicle upright.
31
Hubcaps
Hubcaps
33
• While pressing down on the steering wheel, grasp the steering
column under the dash and pull it up as far as it will go.
• Insert the 5 /
32
" x 1 1 /
2
" pin through the hole in the end of the
steering column.
• Grasp the steering column again under the dash. Pull the steering
column down to fit the pin into the grooved area in the center of the
steering wheel.
Press Wheel Press Wheel
Lift Steering Lift Steering
Column Column
Press Wheel
Lift Steering
Column
5 /
32 32
" x 1 " x 1 1 /
2
" Pin " Pin
• Position the steering wheel so that the tab is upright.
• Fit the steering wheel onto the end of the steering column.
32
Steering
Wheel Tab
Steering
Column
INSIDE VIEW
29
• Fit a wheel retainer onto the end of the rear axle.
Wheel Retainer
• Insert a screw through the large opening in the wheel retainer and
the hole in the rear axle. Tighten the screw.
• Push the axle into the wheel as far as it will go.
• Repeat this procedure to assemble the other rear wheel to the
other end of the rear axle.
30
5 /
32
" x 1 1 /
2
" Pin
