VFY-SCED103S, edition 1 37
Technical data
Electrical data
Regulations complied with:
IEC60950 -1/EN60950-1
Protection class: I
Rated voltage range: 100 - 127 / 200 - 240 V
Frequency: 47 Hz - 63 Hz
Dimensions
Width/depth/height: 333 mm/370 mm/100 mm
Weight
with the basic configuration approx. 10 kg
Environmental conditions
Environment class (3K2)
Environment class (2K2) DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature:
● Operating
(3K2)
● Transport (2K2)
15 °C .... 35 °C
-25 °C .... 60 °C
Condensation in operating must be avoided.
Clearance required to ensure adequate ventilation
Horizontal operating position:
● front
● rear
● left
● right-hand
side
min. 200 mm
min. 200 mm
min. 200 mm
min. 200 mm
Vertical operating position:
● front
● rear
● top min. 200 mm
min. 200 mm
min. 200 mm
i
The data sheet of the device contains further technical data. You will find the data sheet
on the internet at www.fujitsu-siemens.com.
