System expansions
VFY-SCED103S, edition 1 29
Disconnecting cables
► Lift the drive cage slightly and disconnect
the wires from the drives.
Removing the drive cage
1
2
► Lift the drive cage into a vertical
position (1).
► Pull the drive cage out of the casing in the
direction of the arrow (2).
Installing the drive cage
The following steps should be taken when assembling the drive cage:
Attaching the drive cage
1
2
► Place the drive cage onto the front of the
casing. Feed the latches (1) into the
corresponding slits (2).
