Page 39
System expansions
VFY-SCED103S, edition 1
31
Installing the cross-piece
2
1
1
►
Place the cross-beam (2) in the casing and
secure it with the two screws (1). Make
sure that the screw holes are exactly
aligned. Otherwise, turn the cross-beam
over.
►
Close the casing (see "Closing the casing").
Installing and removing drives
In the standard model the device may be equipped with the following drives:
●
one accessible 3 ½ inch drive (floppy drive)
●
one non-accessible 3 ½ inch drive (floppy drive)
●
one accessible 5 ¼ inch drive (e.g. DVD or CD ROM drive)
IDE drives and serial ATA drives
IDE drives and serial ATA drives are supported by default.
