38
Installing the 861
Reference Digital
Surround Controller
Digital inputs – IE44
Use this input To connect to this
D1 to D6* The digital output of a source
such as a DVD player.
O1 and O2 The optical output of a source
such as a satellite receiver or
computer.
SL1 The SpeakerLink output of
a Meridian source with a
SpeakerLink output.
MMHR A multichannel digital source
with an MMHR output, such
as the Meridian HD621 HDMI
Audio Processor.
* D1-D3 and D4-D6 can each be configured as a
multichannel digital input for MHR SmartLink sources.
Extra digital inputs – ID26 (optional)
Use this input To connect to this
O3 to O6 The optical output of a source
such as a satellite receiver or
computer.
SL2 and SL3 The SpeakerLink output of
a Meridian source with a
SpeakerLink output
Sooloos connections – ID40 (optional)
Use this connection To connect to this
Network An Ethernet network, for use
in a Sooloos system.
USB For maintenance of the
Sooloos software.
Communications connections – CO00
Use this connection To connect to this
MERIDIAN COMMS Other Meridian equipment, or
Meridian DSP loudspeakers.
RS232 A computer, for configuring the
861, or a serial control system.
TRIGGER 1, 2, and 3 Equipment that can be
triggered by a 12V 100mA
signal.
