■ DIMENSIONS
Printer mechanism
Unit: mm
Paper insertion
(FTP-631MCL102) (FTP-631MCL101)
R26
21.9
14.2 52.1
106.2
132
Y
Y
40.5
7.5
(300)
11.8
48 35.5
2.5
94.8
Paper insertion
Y-Y SECTION
48 (Head-up)
(Paper center) 28
Location hole
for fixing
3-M3 fixing screw (reference)
Head open
