2-9
2.7 Connecting the Cable
i). Turning the Power Off
Depress the side marked “O” to turn the power off.
Connect the power cable and SCSI signal cable as shown in Figure 2-8.
ii). Turning the Power On
Depress the side marked “I” to turn the power on. The POWER LED will light. If
not, please check the power source.
iii). SCSI Termination
The Fujitsu Scanpartner 15C comes complete with a built in SCSI terminator. If
the Scanner is the last device in a SCSI chain the terminator should be switched
on. If the Scanner is not the last device the terminator should be off. The
terminator on/off switch is located on the back of the Scanner, to the left of the
SCSI cable connectors.
Host PC
Scanner
SCSI Device
Term.
Term.
(Terminator Off)
Host PC
Scanner
Term.
(Terminator On)
