A
8 M3576pr-0726
ASSEMBLY BATTERY CHARGING E
Dash
• Position the dash on the vehicle.
• Make sure the motor harness connector wire is through the groove
in the dash.
• Insert five #10 x 1,9 cm screws into the dash tabs and tighten.
Motor
Harness
Connector
Wire
F
Charger
Connector
A
B
• Plug the charger connector into the battery A .
• Plug the charger into a standard wall outlet B .
Notes:
- The power indicator on the charger does not indicate the charge
status of your battery. The power indicator allows you to see that
there is power from the wall outlet.
- If power flow to the wall outlet is controlled by a switch, make sure
the switch is “ON”.
- Use the charger only in a wall outlet. Do not plug the charger into
a ceiling outlet.
• Before first-time use, charge the battery for at least 18 hours.
Never charge the battery longer than 30 hours.
• Recharge the battery for at least 14 hours after each use of your
vehicle. Do not charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the battery connector from
the charger connector. Unplug the charger from the wall outlet. The
battery is now ready to be installed in your vehicle. Please see the
Battery Installation section on page 18 for detailed instructions on
installing your battery. If your battery is already installed in your
vehicle, simply re-connect the motor harness connector to the battery.
WARNING
Children can be harmed by small parts,
sharp edges and sharp points in the
vehicle's unassembled state, or by electrical
items. Care should be taken in unpacking
and assembly of the vehicle. Children should
not handle parts, including the battery, or
help in assembly of the vehicle.
1
