Furuno CH-37 - Manual (Page 78)

7-4
** DISPLAY TEST **
PROGRAM NO. 0650101-xxx MAIN PANEL
ROM OK * * *
SRAM OK 12 12
VRAM OK 0 255
SIO1 OK 12 0
SIO2 OK 0 0 0
TX FREQUENCY 60KHZ X: 0 Y: 0
ROLL 0 0 0 0
PITCH 0 0
REMOTE CONTROL
0 0 0 255 255 255 *
0 0 0 * *
0 0 0 0 0 0
0 0 0 0 0 0
0 0 0 0 EXIT
0 0 0
SUB PANEL
EXIT : PRESS MENU KEY
ROM Program version
NO. is displayed, ROM
RAM and serial ports
are checked for proper
operation, and Tx fre-
quency, roll angle and
pitch angle are displayed.
Remote Control
Box check. Switch
is normal if value
changes when
switch is operated.
Main panel
check. Switch is
normal if value
changes when
switch is operated.
Sub panel
check. Switch is
normal if value
changes when
switch is operated.
Figure 7-3 Display unit test results
